Product Introduction
The DZM10 Glass Single Edging Machine is a 10-spindle Glass Single Processing Machine engineered for precision and efficiency. This Glass Single Polishing Machine delivers flawless edges across diverse glass products, serving as a cornerstone solution for industrial glass processing.
---
Product Features
Processing Capabilities:
- Ten high-precision spindles for comprehensive operations
- Advanced Glass Single Grinding Machines functionality
- Integrated Glass Single Edge polishing system
- Robust industrial-grade construction
Technical Specifications:
- Handles flat glass, beveled edges, and intricate designs
- Processes diverse glass product dimensions
- Suitable for high-volume and custom production
- Precision-engineered mechanical components
Versatility:
- Unified solution for edging, polishing, and grinding
- Adaptable to complex design requirements
- Consistent performance across operations
---
Product Applications
This Glass Single Processing Machines serves:
- Large-scale glass production facilities
- Custom glass craftsmanship projects
- Architectural glass manufacturing
- Decorative glass fabrication
- Industrial production lines
- Specialized glass workshops
---
Product Advantages
Precision & Quality:
- Delivers smooth and flawless edges
- Ensures uniform finish meeting industry standards
- Maintains dimensional accuracy in grinding
Operational Efficiency:
- Single-platform solution eliminates process changes
- Ten-spindle configuration maximizes throughput
- Reduces production downtime
Versatility & Adaptability:
- Processes flat glass and complex beveled edges
- Handles intricate design requirements
- Scales from mass production to custom projects
Durability & Reliability:
- Robust construction ensures long-term operation
- Consistent performance in demanding environments
- Minimal maintenance requirements
Economic Value:
- Optimizes production line efficiency
- Reduces per-unit processing costs
- Enhances ROI through operational flexibility
---
Technical Summary
The DZM10 redefines versatility as a premier Glass Single Processing Machines, combining 10-spindle power with precision Glass Single Grinding Machines capabilities. This Glass Single Edge polishing solution delivers commercial-grade results for both industrial production and artisanal craftsmanship.
Identification data
Machine: Horizontal edger
Model: DZM10
Voltage and Frequency: 380V, 50Hz
Total power: 20.5Kw
Workable thickness: 3~25mm
Weight: 3200kg
Serial no.:
Product date: 2021
Wheel position with respect to the incoming sheet | ||||||||||||||
DZM10 | ||||||||||||||
Ref.no | No10 | No9 | No8 | No7 | No6 | No5 | No4 | No3 | No2 | No1 | ||||
Rev.(50Hz) | 1400 | 2800 | 2800 | 2800 | 2800 | 2800 | 2800 | 2800 | 2800 | 2800 | ||||
Rev.(60Hz) | 1680 | 3360 | 3360 | 3360 | 3360 | 3360 | 3360 | 3360 | 3360 | 3360 | ||||
Name | Felt wheel | Fine grinding wheel | Fine grinding wheel | Fine grinding wheel | Resin wheel | Resin wheel | Polishing wheel | Fine grinding wheel | Resin wheel | Diamond wheel | ||||
Specification | 150 | 10S60 130×50 | 10S40 130×50 | 130×50 240 mesh | 10S40 130×50 | 130×50 240 | X081 150×50 | 10S40 150×70 | 150×50 240 mesh | 150×50 100 mesh | ||||
Usage | Bottom polishing | Bottom fine grinding | Bottom fine grinding | Semi fine grinding for front arris | Fine grinding for back arris | Semi fine grinding for back arris | Bottom polishing | Bottom fine grinding | Semi fine grinding for bottom | Bottom rough grinding | ||||
Technical data
DZM10 | |
Length [mm] | 7300 |
Width [mm] | 1500 |
Height [mm] | 2500 |
Work top height [mm] | 800±30 |
Total weight [kg] | 3200 |
Workable thickness [mm] | 3～28 |
Minimum glass size [mm]: | 120x120 |
Maximum working weight: | 300 |
per meter of transport [kg / m] | 100 |
Total [kg] | 300 |
Conveyor speed [m / min] | 1～5 |
Tanks: |
|
water [no x l] | 1*165 |
| Rated voltage [V] | See wiring diagram |
Installed power [kW] | 20 |
